Our Carbon Fiber Drone offers versatile performance: 25KM transmission, 120km/h speed, 32min/14min endurance, 7kg/8kg load. It has carbon fiber fuselage, #4216 motor, dual-band transmission & 2K controller. Optional AI Target Tracking Drone module, fiber links & 7kg payload release. 13kg takeoff weight, Betaflight software & full accessories for inspection/rescue/monitoring (3-axis Gimbal Folding Drone).
VX-Motor HY-YTZD Highlight:
- Ultra-long distance reliable operation
- High-speed flight and rapid response
- Long endurance and stable load
- Strong load capacity with multi-task support
- HD anti-interference image transmission
- Intelligent identification and automatic tracking
| Specification： | |
| Weight | 2.6 kg |
| Input Voltage | 6S |
| Frame | Industrial-grade frame |
| Wheelbase | 680mm |
| Dimensions | L446mm × W516mm × H280mm |
| Material | Carbon fiber plate |
| Flight Controller | S2 Pro Edition F407 |
| ESC | AM32 4-in-1 Brushless 100A ESC |
| VTS | 15km HD digital video transmission(integrated into flight controller)5.8G & 2.4G Dual-Link Transmission |
| Camera | C10Pro Compact HD 3-Axis Gimbal Camera |
| Motors | #4216 KV:380 |
| Propellers | Tuofei 15-inch Propellers |
| Control Range | 25km |
| Max Speed | 120km/h |
| Max Flight Range | 25km |
| Rated Payload | 7000g |
| Maximum Payload | 8000g |
| Max Takeoff Weight | 13000g |
| Empty Flight Duration | 32 min 6s (1000mAh) |
| Payload Flight Duration | 14 min 6s (10000mAh) at 3kg |
| Accessories： | |
| *Remote controller, batteries, charger5.8GHz long-range antenna*1 | |
| *25mm×350mm battery strap*1 | |
| *Propeller 1507 (carbon fiber nylon) - CW/CCW (1 pack) | |
| Optional Modules： | |
| *Infrared Thermal Imaging Module | |
| *Fiber-Optic Communication Link (Radio-Interference Resistant): Available in 3km, 5km, 10km, 15km lengths | |
| *Payload Release System (Maximum 7kg) | |
| Packing info: | |
| Product net weight (g) | 2600g |
| Product dimension (mm) | 446mm × 516mm × 280mm |
| Box gross weight (g) | 2970g |
| Box dimension (mm) | 530*530*140 |
| Carton weight (kg) | 5.08 |
| Carton dimension (mm) | 433*330*330(1 set) |
